| Body
: KIC Self Centering Chucks are supplied in semi steel bodies. Semi-steel
alloyed body is casted with the addition of alloys like chromium, nickel, copper
mangnese etc. Hardness 190-200 Bhn. |
| Jaws
: Jaws are of
case hardening steel and are properly case hardened and tempered for ensuring
reliability and durability. Faces of internal and external jaws are ground on
both sides and are tested for ensuring quality and accurancy. Hardness 55-60 Hrc. |
| Scrolls
: Scrolls are
manufactured from carbon and steel and are properly heat treated for ensuring
quality durability. Hardness 25-30 Hrc. |
| Pinion
Gears : Pinion
Gears are manufactured from the solid tough alloy steel and have a square recess
to be operated with the chuck operating key. Hardness 40-45 Hrc. |
| Chuck
Operating Key : Chuck Operating Key is manufactured with Hardened and tempered
alloy steel of suitable length. |
| Guarantee
: KIC Self Centering Chucks bear guarantee of one year against any manufacturing
defect. |
| Standard
Equipment : Every KIC Self Centering Chuck is provided with One set of reversable
jaws, One operating key, Inspection Chart and a set of Mounting Bolts. |
